Name: 140DDI84100 DC discrete input module
Brand: Xiamen Online Union Technology Co., Ltd
SKU: 140DDI84100
Price: 99 USD
Availability: InStock

Home Products Schneider Module

140DDI84100 DC discrete input module

Product Details:

Place of Origin:	China
Brand Name:	Schneider
Model Number:	140DDI84100

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	$99
Packaging Details:	New sealed
Delivery Time:	In stock/1-3days
Payment Terms:	T/T
Supply Ability:	5000

Contact Now

Detailed Product Description

Highlight:

industrial automation schneider module

automation control schneider module

plc controller schneider module

140DDI84100 Schneider Relay Module

140DDI84100 is a DC discrete input module launched by Schneider Electric, belonging to the Modicon Quantum automation platform product. The module has 16 discrete input points, divided into 8 channels, which can be connected to field devices such as switches and sensors that can output digital signals. Each input channel can receive a voltage signal of 10-60V DC and is compatible with various DC voltage sensors and devices. For source type (PNP) and drain type (NPN) sensors, the module can be flexibly adapted through its sink/source capability; The module adopts electrical isolation technology, with isolation barriers set between the input side and internal circuits. The isolation voltage between each channel and the bus is 2500Vrms DC, and the isolation voltage between groups is 700Vrms DC, which can effectively suppress common mode interference and surge voltage; The module is equipped with LED status indicator lights for each input channel. When a signal is input to a certain input channel and correctly recognized by the module, the corresponding LED light will light up in green to facilitate operators to intuitively understand the input status of each channel; The module encodes and processes the input signal, converts it into digital form, communicates with other modules of the PLC through the backplane bus, and transmits the collected input signal status data to the CPU. In some cases, it may be equipped with communication interfaces such as Modbus RTU to facilitate connection and data exchange with other devices that support corresponding communication protocols. It can achieve remote monitoring, parameter setting, and fault diagnosis functions, facilitate system integration and management, and is widely used in industrial automation control systems.

Technical specifcations for 140DDI84100

Input quantity and channel group:
Discrete input quantity: 16
Channel group: 8
Input voltage and current:
Input voltage limit: 10-60V
Range of input current at different voltages:
At 60V: 1~5mA DC
At 48V: 2-15mA DC
At 24V: 6-30mA DC
At 12V: 5-10mA DC
Input logic and address requirements:
Input logic: positive (heat sink)
Address requirement: 1 input word
Voltage state guarantee:
Voltage State 1 Guarantee:
When 9-12V: 12V+/-5%
At 45-60V: 60V+/-20%
Between 34-48V: 48V+/-20%
Between 11-24V: 24V+/-20%
Voltage state 0 guarantee:
When 0-9V: 60V+/-20%
When 0-5V: 24V+/-20%
When 0-10V: 48V+/-20%
When 0-1.8V: 12V+/-5%
Reaction time:
Response time from 1 to 0: 4ms
Response time from 0 to 1: 4ms
Insulation and current:
Insulation between groups: 700Vrms DC, lasting for 1 minute
Required bus current: 200mA
power waste:
Power consumption W: 1W+(0.62 x number of powered points)
Local signal and LED indication:
Local signal: 16 LED green lights for input status (1 to 32), 1 LED red light for detecting external faults (F), 1 LED green light for bus communication in progress (active)
Product weight:
Product weight: 0.3kg
