140ACI05100 analog input module

Product Details:

Place of Origin:	China
Brand Name:	Schneider
Model Number:	140ACI05100

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	$99
Packaging Details:	New sealed
Delivery Time:	In stock/1-3days
Payment Terms:	T/T
Supply Ability:	5000

Contact Now

Detailed Product Description

Highlight:

industrial automation schneider module

automation control schneider module

plc controller schneider module

140ACI05100 Schneider Relay Module

140ACI05100SC is an analog input module for Schneider Electric's Modicon Quantum series PLC, designed specifically for industrial automation scenarios. It supports converting on-site analog signals (such as temperature, pressure, flow, etc.) into digital signals that can be processed by a programmable logic controller (PLC). This module adopts high-precision 12 bit or 14 bit analog-to-digital converters (the specific number of bits needs to be confirmed in the product manual), supports multi-channel inputs (such as 8 or 16 channels), can handle multiple current/voltage signal ranges (such as 4-20mA, 0-20mA, 0-25mA or 1-5VDC), and has channel isolation function to reduce signal interference. Its wide temperature working range (-20 ℃ to+60 ℃ or higher, depending on the model) and anti electromagnetic interference capability (compliant with IEC 801-2/3 standard) ensure stable operation in harsh industrial environments, suitable for fields such as process control and environmental monitoring that require high-precision data acquisition. The module is integrated with the PLC system through standard industrial interfaces (such as DIN rail installation), supports hot swapping and redundant configuration, and is easy to maintain and expand.

Technical specifcations for 140ACI05100

Manufacturer and Series:
Manufacturer: Schneider Electric
Series: Modicon Quantum
Type and Function:
Type: IO module, specifically analog input module
Input channel and resolution:
Analog input quantity: 8 channels (there is also information indicating the possibility of a 16 channel version, but for 140ACI05100SC, it usually refers to 8 channels)
Analog input resolution: 12 bits
Input type and range:
Input type: differential input
Linear measurement range: 1... 5 volts, 4... 20 milliamps
Accuracy and Error:
Absolute accuracy error:+/-0.1% of full scale (there is also information indicating that accuracy error may be+/-0.05% of full scale, depending on measurement conditions and configuration)
Linear error:+/-0.04%
Accuracy drift with temperature:<=0.0050% full-scale/° C (there is also information indicating+/-0.0025% full-scale/° C)
Isolation and common mode rejection:
Isolation between channel and bus: 3000 V DC for 60 seconds (there is also information indicating 1000 V DC isolation)
Channel isolation: 30V DC
Common mode rejection:>-72 dB (60 Hz)
Input impedance and load:
Input impedance: For voltage input, the impedance is relatively high (e.g.>20 megaohms); For current input, the impedance is 250 ohms+/-0.01%
Fault detection and local signaling:
Fault types: including undervoltage range (1... 5 volts) and disconnection (4... 20 milliamps)
Local signaling: Display channel status through LED indicator lights (such as green indicating channel open, red indicating channel fault or external fault)
Electrical parameters:
Requirement bus current: The specific value may vary depending on configuration and usage conditions, but it is usually provided in the module specification document
Power consumption: relatively low, the specific value also depends on the working state and configuration of the module
Environmental adaptability:
Operating temperature range: typically suitable for industrial environments, such as 0... 60 ° C (specific range may vary depending on product version and configuration)
Storage environment temperature: -40... 85 ° C
Relative humidity: 95% (without condensation)
Working altitude:<=5000 meters
