140ERT85420 multifunctional input module

Product Details:

Place of Origin:	China
Brand Name:	Schneider
Model Number:	140ERT85420

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	$99
Packaging Details:	New sealed
Delivery Time:	In stock/1-3days
Payment Terms:	T/T
Supply Ability:	5000

Contact Now

Detailed Product Description

Highlight:

industrial automation schneider module

automation control schneider module

plc controller schneider module

140ERT85420 Schneider Relay Module

140ERT85420 is a multifunctional input module for Schneider Electric's Modicon Quantum automation platform, with 16 discrete input channels (suitable for 24V to 125V DC/AC), supporting high-frequency counting (500Hz) and time/date stamping functions, capable of recording discrete input status changes and generating event logs. This module achieves electrical isolation between channels through optocoupler isolation technology, supports configurable anti shake filtering (0-255ms) and reverse configuration of input status, is compatible with DCF77/IRIG-B time synchronization protocol, and is suitable for joint Pro V5.0 and above version control systems. Its electrical interface supports shielded cables (≤ 600m) or unshielded cables (≤ 400m), equipped with 32 LED indicator lights to display input status in real time, and integrates self checking and fault diagnosis functions (prompted by LED indicator lights). The module adopts a screw terminal connection method, supporting 5V DC bus (300mA) and 24-125V DC external power supply (20mA per channel), complying with IEC 801-2 anti-static discharge (4kV contacts/8kV broadcast) and IEC 801-3 anti electromagnetic interference (10V/m, 80-2000MHz) standards, with a working temperature range of 0-60 ° C and a storage temperature of -40-85 ° C. It is suitable for high-precision acquisition and processing of input signals in the field of industrial automation.

Technical specifcations for 140ERT85420

Brand and model: Schneider 140ERT85420, belonging to Modicon Quantum automation platform.
Product type: Multi functional input module, supporting SOE (sequence of events recording) function.
Input channel and type:
Number of channels: 16 discrete input channels.
Input type: Supports inputs from 24V to 125V DC/AC.
Counting and timestamp function:
Supports high-frequency counting, with a counting frequency of up to 500Hz.
Equipped with time and date stamping function, it can record the status changes of discrete inputs and generate event logs.
Electrical isolation and anti shake filtering:
Realize electrical isolation between channels through optocoupler isolation technology.
Support configurable anti shake filtering, with a filtering time range from 0 to 255ms.
Reverse configuration of input states: Supports reverse configuration of input states to meet different application requirements.
Time synchronization protocol: compatible with DCF77/IRIG-B time synchronization protocol (specific support may vary depending on system version).
Electrical connections and cables:
Support the connection of shielded and unshielded cables.
The length of shielded cable can reach 600m, and the length of unshielded cable can reach 400m.
Wiring method and LED indicator light:
Use screw terminal connection method.
Equipped with 32 LED indicator lights for real-time display of input status.
Power supply and power consumption:
Supports 5V DC bus (300mA) and 24-125V DC external power supply (20mA per channel).
The power consumption does not exceed 7.5W.
Environmental adaptability:
Working temperature range: 0 ° C to 60 ° C.
Storage temperature range: -40 ° C to 85 ° C.
Relative humidity: 95% (without condensation).
Working altitude: not exceeding 5000m.
Electromagnetic compatibility and protection level:
Anti static discharge: 4kV (contact), in accordance with IEC 801-2 standard; 8kV (broadcast), compliant with IEC 801-2 standard.
Anti electromagnetic interference: 10V/m (80-2000MHz), in compliance with IEC 801-3 standard.
Certification and Standards:
Product certification: CE, CCC, etc
