140DDI35310 Schneider Relay Module
140DDI35310 is a digital input module from Schneider Electric's Modicon Quantum series, designed specifically for industrial automation control systems. It features high reliability and modular design, supports multi-channel digital input (usually 16 or 32 channels, depending on the model configuration), and is compatible with dry or wet contacts. The input voltage range is usually DC 24V (specific values need to refer to the data manual), with a response time of less than 1ms. The power supply voltage is DC 24V (± 10%), and the power consumption is usually a few watts. The operating temperature range is 0 ° C to 60 ° C, and the storage temperature range is -40 ° C to 85 ° C. The protection level reaches IP20. It can communicate with Modicon Quantum PLC through the backplane and supports online communication. Diagnostic and troubleshooting functions, easy to maintain, in compliance with International Electrotechnical Commission (IEC) standards and CE Certification is widely used in automation production lines, process control systems, and equipment monitoring scenarios. It is compatible with Modicon Quantum series PLCs and other modules and can be flexibly integrated into various industrial control systems.
Technical specifcations for 140DDI35310
Input channel: 32 channel digital input, supports high-density signal acquisition, input voltage is 24V DC (standard type), compatible with 10-30V DC wide voltage input, input logic is negative (source), divided into 4 groups, each group has 8 channels.
Electrical characteristics:
Input impedance: 2400 ohms.
Leakage current: 200mA at Us=5.5V and Uin=4V.
Absolute maximum input: 50V (attenuated pulse within 1ms), 30V (continuous).
Power consumption: 1.5W+(0.26 x number of energized points).
Response time: ≤ 1ms (state from 1 to 0 or from 0 to 1).
Signal indication:
32 green LEDs for displaying input status (1 to 32).
1 red LED for detecting external faults (F).
One green LED is used to indicate that bus communication is in progress (active).
Isolation and protection:
Inter group insulation: 500Vrms, lasting for 1 minute.
Isolation technology: Adopting photoelectric isolation technology, the isolation voltage reaches 2500V AC, enhancing anti-interference ability.
Communication and compatibility:
Communication interface: Supports mainstream industrial communication protocols such as Modbus TCP/IP and Ethernet/IP, and is compatible with Quantum PLC systems.
Address requirement: 2 input words.
Environmental adaptability:
Working temperature: The standard model ranges from 0 ° C to 60 ° C, while the extended model can reach -40 ° C to+70 ° C, suitable for harsh industrial environments.
Storage temperature: -40 ° C to+85 ° C.
Protection level: IP20 (some materials mention IP30 protection level, which may vary depending on product version or configuration).
Installation and maintenance:
Installation method: Standard DIN rail installation, supports hot swapping, and is easy to maintain.
Product weight: approximately 0.3kg.
