140CPU67260 Schneider Relay Module
140CPU67260 is a multi-mode processor launched by Schneider Electric, belonging to the Modicon Quantum automation platform. It adopts the Unity processor architecture and has multi-mode communication capabilities, supporting real-time data processing and industrial Internet of Things (IIoT) applications. It realizes device interconnection through integrated Ethernet, Modbus Plus, Profibus DP and other communication interfaces, and is suitable for industrial automation control scenarios. The processor is equipped with a 266MHz clock frequency, built-in 3072kB RAM (1536KB data storage), supports PCMCIA memory expansion cards to expand program storage to 8MB, and is configured with multiple sets of I/O interfaces (including 8000 input/8000 output distributed channels and 31744 input/31744 output remote channels). It can connect 63 distributed I/O stations and 31 remote I/O stations to meet the needs of complex systems. Its dual LED indicator lights display configuration status and Ethernet activity respectively. The electrical interface includes single-mode fiber LC connector, SUB-D 9-type Modbus Plus connector, and RJ45 type Modbus bus connector. It is compatible with 10 kilometer master-slave PLC communication and has international certifications such as CE, CSA, GOST, UL, etc. It is suitable for real-time monitoring and automation tasks in manufacturing, power systems, oil and gas, and other fields.
Technical specifcations for 140CPU67260
Product series and types:
Product Series: Modicon Quantum Automation Platform
Product or component type: Unity processor
Transmission mode and clock frequency:
Transmission mode: multi-mode
Clock pulse frequency: 266 MHz
I/O points and number of stations:
Number of distributed I/O stations: 63 stations (1 rack, 3 Modbus Plus networks)
Number of remote I/O stations: 31 stations (2 backboards)
Discrete I/O number: 8000 input, 8000 output (distributed, per network); 31744 inputs, 31744 outputs (remote)
Simulated I/O count: 500 inputs and 500 outputs (distributed, per network); 1984 inputs, 1984 outputs (remote)
Memory Description:
Internal RAM: 3072 kB (data storage of 1536 kB)
Scalable memory:
Program: 7168 Kb (with PCMCIA card)
File storage: 8 MB (with PCMCIA card)
Switch function and task structure:
Switch function: key switch, power on/off of memory port
Task Structure:
Fast task for one cycle (prohibiting the use of hot standard equipment)
128 I/O interrupt tasks (prohibit the use of hot standard devices)
128 interrupt tasks (prohibiting the use of hot standard equipment)
32 timer interrupt tasks (prohibit the use of hot standard devices)
4 auxiliary tasks (prohibiting the use of thermal standard equipment)
1 cycle/periodic main task
Instruction execution time and system overhead:
Accurate time for each instruction:
Floating point: 0.4... 0.5 μ s
Boolean: 0.0525... 0.075 μ s (10.28 Kin/ms for 100% Boolean, 10.07 Kin/ms for 65% Boolean and 35% arithmetic)
Word for word: 0.045... 0.06 μ s
Fixed point arithmetic: 0.045... 0.06 μ s
System overhead:
Main task: 1 ms
Quick Task: 0.2 ms
Demand bus current and local signal:
Required bus current: 2760 mA
Local signal:
1 LED (yellow) for configuration status (STS)
1 LED (yellow) for Ethernet activity (COM)
Electrical connections and connector types:
Electrical connection:
1 connector, connector type: LC (single-mode fiber), used for connecting primary and secondary PLCs, up to 10 kilometers
1 hole type connector, connector type: SUB-D 9, used to connect to Modbus Plus network
1 connector, connector type: RJ45, used for connecting Modbus bus
Environmental certification and standards:
Product certification: CE, CSA, GOST, UL, etc
Standard: HazLoc
Packaging and Warranty:
Packaging information:
Height 11.0 cm, width 18.5 cm, length 32.5 cm, weight 1.424 kg
