TSXP57153M Schneider Relay Module
TSXP57153M is a Premium series PLC processor launched by Schneider Electric, which has high performance and reliability. It adopts a modular design to support flexible expansion, and is equipped with a main processor and co processor architecture to achieve efficient operation and communication processing. It supports standard industrial Ethernet protocols such as Modbus TCP/IP, and is equipped with a 12Mbps backplane bus and USB high-speed programming port. It integrates real-time clock, ample registers, and multilingual programming environment, is compatible with IEC61131-3 standard, supports LD/FBD/ST/SFC/IL and other programming methods, and can provide up to 7MB of CPU memory expansion space. Its SOE accuracy is strictly controlled within 5ms, and it supports hot standby redundancy technology to ensure the real-time, deterministic, and high availability of industrial control systems in complex environments.
Technical specifcations for TSXP57153M
Brand: Schneider Electric
Model: TSXP57153M
Product type:
PLC programmable controller, belonging to Schneider Electric's Premium series
Structural form and installation method:
Structural form: modular
Installation method: Supports control room installation or on-site installation, depending on the application scenario and user needs
I/O points:
The number of I/O points may vary depending on the specific configuration, but typically supports a certain number of input and output points to meet control requirements of different scales. There is information indicating that its I/O point count is 24 inputs/16 outputs, but this may not be the standard value for all configurations.
Program capacity:
The program has a large capacity, such as 256kbyte, which can meet the requirements of complex control logic.
Execution speed:
The execution time of Boolean instructions is only 37ns, and the execution time of numerical instructions is only 45ns, ensuring the high-speed computing capability of the processor.
Communication ability:
Supports standard industrial Ethernet protocols such as Modbus TCP/IP, with a communication speed of no less than 100Mbps.
The communication rate of the backplane bus is a constant 12Mbps, which does not attenuate with the increase of rack and communication distance, ensuring the real-time and deterministic performance of the system.
Ethernet supports IO scanning mode, which can automatically identify various devices on the Ethernet network, making it convenient for users to add or remove devices in real-time online and easy to maintain.
Memory expansion:
The CPU memory can be expanded to 7MB, ensuring sufficient available program space.
Real time clock and registers:
The CPU has a built-in real-time clock that can provide time stamps for all information.
The CPU has ample registers to choose from to meet the needs of different control logics.
Hot standby redundancy technology:
Based on Modicon Quantum's mature hot standby technology, we provide reliable, open, and economical hot standby solutions.
SOE accuracy:
The SOE accuracy is strictly guaranteed to be within 5ms, ensuring that the cause of the fault can be accurately and timely identified when it occurs.
Programming software and language:
The PLC programming software complies with the IEC61131-3 standard and provides programming languages such as LD (ladder diagram), FBD (function block diagram), ST (structured text), SFC (sequential function diagram), IL (instruction list), etc. to achieve offline simulation functionality.
Other features:
The CPU integrates Ethernet and a 12Mbps USB high-speed programming port, making it convenient for users to program and debug.
The CPU module integrates multiple processors, with the main processor handling program operations and the co processor handling communication, ensuring high system availability.
