170ADO35000 Schneider Relay Module
170ADO35000 is a PLC module launched by Schneider Electric, belonging to the Modicon Momentum automation platform. As a discrete thyristor I/O base AC module, it has the functions of discrete input number 10 (IEC 1131-2 type) and discrete output number 8 (discrete output thyristor). The input voltage is limited to 74 to 132V, the network frequency is 47 to 63 Hz, and it supports discrete output voltage of 120 to 132V DC. It is equipped with an internal 2 × 2.5A slow melting fuse protection. The module structure is compact, weighs only 0.22kg, and the size is 125mm × 145mm × 45mm. It has passed UL and CSA certification and meets CE standards. It has anti-static discharge (4kv contact IEC 801-2, 8kV air). IEC 801-2) and anti electromagnetic field (9.14V/m, 80 to 1000MHz IEC 801-3) capabilities, operating temperature range 0 to 60 ° C, storage temperature range -40 to 85 ° C, Suitable for discrete input-output control scenarios in the field of industrial automation.
Technical specifcations for 170ADO35000
Brand and Model: Schneider Electric, Model 170ADO35000.
Product type: Belonging to Modicon Momentum automation platform, it is a discrete thyristor I/O base AC module.
Input/output configuration:
Discrete input number 10 (IEC 1131-2 type 2), discrete input voltage range of 74 to 132V AC, network frequency of 47 to 63 Hz.
Discrete output number 8, discrete output type thyristor, with a discrete output voltage range of 120 to 132V DC.
Electrical characteristics:
The input resistance is 4kohm, the discrete output current for each group is 2A, the total module current is 4A, the current range for each point is 30mA to 0.5A, and the leakage current is 1.3mA.
The voltage drop of the output circuit in state 1 is less than 1.5V (under 0.5A load), and the operating rate is 3000 cyc/h (under 0.5A inductive load).
Response time: The input and output state changes are both 1/2 x 1/f (f is the frequency).
Isolation and protection:
The isolation voltage between the channel and the bus is 1780V AC.
The power consumption is less than or equal to 8W (typical value is 6W), and the protection type is an internal 2 × 2.5A slow melting fuse.
Physical dimensions and weight:
The depth is 47.5 millimeters (1.87 inches), the height is 141.5 millimeters (5.57 inches), and the width is 125 millimeters (4.92 inches).
The net weight is 0.22 kilograms (0.49 pounds).
Environmental adaptability:
The working temperature range is 0 to 60 ° C (32 to 140 ° F), and the storage temperature range is -40 to 85 ° C (-40 to 185 ° F).
The relative humidity can reach 95% (no condensation), and the working height does not exceed 5000 meters (16404.2 feet).
Certification and Standards:
Product certifications include UL and CSA, and comply with CE standards.
The anti-static discharge capacity is 4kV contact (IEC 801-2) and 8kV air (IEC 801-2).
The anti electromagnetic field capability is 9.14V/m (80 to 1000MHz, IEC 801-3).
