140DAI75300 VAC discrete input module

Product Details:

Place of Origin:	China
Brand Name:	Schneider
Model Number:	140DAI75300

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	$99
Packaging Details:	New sealed
Delivery Time:	In stock/1-3days
Payment Terms:	T/T
Supply Ability:	5000

Contact Now

Detailed Product Description

Highlight:

industrial automation schneider module

automation control schneider module

plc controller schneider module

140DAI75300 Schneider Relay Module

140DAI75300 is a VAC discrete input module launched by Schneider Electric. It has 32 discrete input channels and uses 230V AC voltage input. It supports dual frequency band operation of 47-63Hz and 57-63Hz. The input current is 9.7mA at 47-53Hz and 11.5mA at 57-63Hz. The voltage state 1 guarantee range is 175-264V AC (47-53Hz) and 165-264V AC (57-63Hz), and the state 0 guarantee range is 0-40V AC. The input impedance reaches 26500 Ω (capacitive load), suitable for signal acquisition of sensors, switches and other discrete devices in industrial automation systems. It can convert discrete signals into digital signals for supply. Control system processing is widely used in manufacturing, energy, water treatment, chemical, power and other fields, helping to achieve real-time monitoring and precise control of industrial processes.

Technical specifcations for 140DAI75300

Brand and model Schneider Electric, model 140DAI75300.
Input quantity and type: 32 discrete inputs, AC voltage input.
Input voltage 230V AC, voltage state 1 guarantee range is 175-264V AC (47-53Hz), 165-264V AC (57-63Hz); The voltage state 0 guarantee range is 0-40V AC (47-53Hz and 57-63Hz).
The input current is ≤ 9.7mA between 47-53Hz and ≤ 11.5mA between 57-63Hz.
The input impedance is 31800 ohms (capacitive) between 47-53Hz and 26500 ohms (capacitive) between 57-63Hz.
Leakage current ≤ 2.6mA.
Absolute maximum input 400V (1 cycle), 312V (10s), 264V (continuous).
The reaction time is 7.3-12.3ms for on-off and 4.9-0.75ms for on-off, multiplied by the line cycle.
Inter group insulation 1780Vrms, lasting for 1 minute.
The required bus current is 250mA.
Power consumption ≤ 5W.
32 green LEDs for local signal indication, used to indicate input status (1 to 32); 1 red LED for detecting external faults (F); One green LED is used to indicate that bus communication is in progress (active).
The product weighs 0.3kg.
