140DDO35310 Quantum series DC discrete output module

Product Details:

Place of Origin:	China
Brand Name:	Schneider
Model Number:	140DDO35310

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	$99
Packaging Details:	New sealed
Delivery Time:	In stock/1-3days
Payment Terms:	T/T
Supply Ability:	5000

Contact Now

Detailed Product Description

Highlight:

industrial automation schneider module

automation control schneider module

plc controller schneider module

140DDO35310 Schneider Relay Module

140DDO35310 is a Quantum series DC discrete output module launched by Schneider Electric. It has a 32 channel positive logic source output function, uses 24V DC power supply, and integrates 4 sets of 8-channel isolation design. It supports a maximum load current of 0.5A/channel and a total output capacity of 16A/module. It has a fast state switching response time of ≤ 1ms and is equipped with 5A/set fuses for internal output protection. It has 32 built-in green LED indicator lights to display channel status in real time, and integrates red fault indicator lights and green bus communication indicator lights. The module improves power supply reliability through dual power redundant input (DC9-36V) and DC1500V voltage isolation technology. It adopts a 35mm DIN rail installation method and IP30 The wave patterned aluminum reinforced casing with protection level can adapt to harsh industrial environments ranging from -10 ℃ to 70 ℃ and 90% relative humidity (without condensation).

Technical specifcations for 140DDO35310

Brand and model Schneider Electric, model 140DDO35310.
Output quantity and type: 32 channel positive logic source output, DC discrete output module.
Output voltage 24V DC.
Power consumption of 2.0W+(0.4V x total load current).
Channel group 4, with 8 channels in each group.
The voltage drop is 0.4V at a load current of 0.5A.
Address requires 2 output words.
Absolute maximum output of 50V for 1-second decay pulse.
The maximum load current is 4A per group and 16A per module.
Surge current ≤ 5A, lasting for 1ms.
Reaction time ≤ 1ms (during the transition from state 1 to state 0 and from state 0 to state 1).
Protection type: Each group is equipped with internal output protection with 5A fuses, and the relevant fuse level is 5A per group and 3A per point.
32 green LED indicator lights for local signal indication, used to display the input status of channels 1 to 32; 1 red LED indicator light for detecting external faults (F); 1 green LED indicator light, used to display that bus communication is in progress (active).
The required bus current is ≤ 330mA.
The product weighs 0.45kg.
The leakage current is 0.4mA under a 30V load.
The insulation performance between each channel and the bus is 1780Vrms DC, lasting for 1 minute; The insulation between groups is also 1780Vrms DC, lasting for 1 minute.
The power supply and redundancy support dual power supply redundant input, with a voltage range of DC9-36V and a typical operating voltage of DC24V. The power consumption is less than 4W, and it has DC1500V voltage isolation and reverse protection functions.
The mechanical characteristics and external dimensions are 132mm × 105mm × 52mm, and the shell is a corrugated aluminum reinforced shell with IP30 protection level. The installation method is 35mm DIN rail installation, with a net weight of 800g.
The working environment has a temperature range of -10 ℃ to 70 ℃ (with a wide temperature range of -40 ℃ to+85 ℃), a relative humidity of ≤ 90% (without condensation), and a storage temperature range of -40 ℃ to 80 ℃.
The testing and certification comply with relevant standards such as EN55022:2010 (RE), EN61000-4-2:2001 (ESD), EN61000-4-3:2006 (RS), etc.
