140DDO84300 Schneider Relay Module
140DDO84300 is a discrete output module in the field of industrial automation launched by Schneider Electric. It belongs to the Quantum series and has 16 discrete output capabilities. The output voltage range is 10.2 to 72V, and the bus current requirement is 160mA. It adopts a standard format design and is a non customized product suitable for conventional industrial system environments. It can provide energy for output devices such as solenoid valves, motor starting coils, and indicator lights. Its modular design is suitable for various industrial automation scenarios and plays a key role in industrial control systems with stable and reliable output performance, ensuring efficient operation of equipment.
Technical specifcations for 140DDO84300
Brand and model Schneider Electric, model 140DDO84300.
Output quantity and type: 16 channel discrete output, DC discrete output module, output logic is negative logic (trap).
The output voltage range is 10.2 to 72V DC, and the output voltage is limited to 10.2 to 72V. The absolute maximum output is constant at 72V.
The output current is 0.5A per channel (some information mentions that the maximum load current for each group is 6A, with 2A per point, and the appropriate fuse needs to be selected according to the actual load configuration).
Response time ≤ 1ms (during the transition from 1 state to 0 state and from 0 state to 1 state).
Channel group 2, with 8 channels in each group.
Each group is equipped with 8A fuses for internal output protection, with a corresponding fuse level of 8A per group and 2A per point.
Power consumption is 1W+(1V x total module load current).
Voltage drop ≤ 1V (under 2A load current).
Surge current ≤ 7.5A (for 50 seconds).
Leakage current ≤ 1mA (at 60V).
The insulation performance between each channel and the bus is 2500Vrms DC, lasting for 1 minute; The insulation between groups is 700Vrms DC, lasting for 1 minute.
16 green LED indicator lights for local signal indication, used to display the output status of channels 1 to 16; 1 red LED indicator light for detecting external faults (F); 1 green LED indicator light, used to display that bus communication is in progress (active).
The required bus current is ≤ 160mA.
The product weighs 0.45kg.
The working temperature range for environmental adaptability is 0 to 60 ° C, the storage environment temperature is -40 to 85 ° C, the relative humidity is ≤ 95% (no condensation), and the altitude is ≤ 5000m.
Product certification complies with CE, C-Tick, FM (Class 1, Division 2) GOST RMRS, Standard CSA C22.2 No 142, UL 508 and other international standards, anti static discharge 8kV broadcasting (compliant with IEC 801-2), 4kV contacts (compliant with IEC 801-2), anti electromagnetic domain 10V/m (80 to 2000MHz, compliant with IEC 801-3).
