140NOC78100 Schneider Relay Module
140NOC78100 is a Quantum series Ethernet control network module launched by Schneider Electric, equipped with 4 Ethernet ports (supporting 3 IP addresses), integrated routing function for cross network communication, supporting RSTP ring network and distributed IO daisy chain topology, with hot backup redundancy architecture and NTP time synchronization function, built-in 4-port switch and web server, compatible with Modbus TCP and EtherNet/IP protocols, supporting up to 64 IO scanning sub stations (shared with Ethernet/IP and Modbus TCP), and requiring configuration through Unity Pro V7.0 software. Its modular design can adapt to the network requirements of the control layer and field device layer in industrial automation scenarios, ensuring system reliability through redundant architecture and protocol compatibility.
Technical specifcations for 140NOC78100
Brand and model Schneider Electric, model 140NOC78100.
Output/input type Ethernet control network module with embedded 4-port switch function.
The communication port protocol supports Modbus TCP and EtherNet/IP protocols.
The transmission rate is 10/100 Mbit/s.
The number of Ethernet ports integrates 4 Ethernet ports (supporting 3 IP addresses).
Redundancy and topology support hot backup redundancy architecture, with RSTP ring network and distributed IO daisy chain topology functions.
The web server is equipped with an embedded web server that supports configuration and monitoring through web pages.
The communication service supports embedded routers, SNMP agents, Quality of Service (QoS), SMTP email notifications, and other functions.
LED indicator lights are equipped with multiple LED indicator lights to display communication, configuration status, module status, network communication status, etc. on the bus.
The operating temperature range for environmental adaptability is 0 to 60 ° C, with a relative humidity of ≤ 95% (no condensation).
The product certification complies with international standards such as UL 508, EN 55011, EN 61131-2, FM Class 1 Part 2, EN 61131-1, IEC 61000-4-16, CSA C22.2 No 142, C-Tick, GOST LR Merchant Shipping, etc.
IP rating IP20.
Net weight 0.345 kg.
The packaging unit is 1 PCE, and the specific size and weight may vary depending on the packaging method.
The configuration software needs to be configured in the Unity Pro V7.0 version software.
The maximum number of IO scanning sub stations is 64 (shared with Ethernet/IP and Modbus TCP).
