140ESI06210 Schneider Relay Module
140ESI06210 is an ASCII interface module launched by Schneider Electric, which belongs to the communication unit in its industrial automation product series. This module is designed specifically for exchanging data information with third-party devices and has asynchronous serial connection capabilities. It can achieve efficient data transmission through two 9-pin SUB-D connectors (RS232C communication ports). The front panel of the module integrates a light-emitting diode array, a restart button, and a user identification tag, making it easy for users to monitor and operate. In addition, 140ESI06210 supports calling additional ESI instructions using Concept and ProWORX programming software in LL984 programmable mode to simplify data exchange management between controller applications and asynchronous serial connection modules. Its compact modular design, standard 35mm DIN rail installation method, and IP30 protection level enable the module to adapt to various industrial environments and provide stable and reliable communication solutions for industrial automation systems.
Technical specifcations for 140ESI06210
Communication interface: The module is equipped with two 9-pin SUB-D connectors (RS232C communication ports), supporting asynchronous serial connections and enabling data exchange with third-party devices.
Status indication: The front panel integrates a light-emitting diode array, including module model and color code, 6 dual color LED status indicators (for power, communication activity, and error status display), movable hinged doors, and user identification tags.
Operation control: Configure a restart button and support manual reset operation.
Programming support: In LL984 programmable mode, additional ESI instructions can be called through Concept and ProWORX programming software to simplify data exchange management between controller applications and asynchronous serial modules.
Electrical specifications:
Power supply: Dual power redundant input, supports a wide voltage range of DC9-36V, typical working voltage is DC24V, power consumption is less than 4W, with DC1500V voltage isolation and reverse protection function.
Communication speed: Supports multiple speeds ranging from 9.6kBit/s to 12MBit/s.
Interface protection: Provides 4000V lightning protection, 1.5A overcurrent protection, and 600W surge protection.
Protection and installation:
Protection level: IP30.
Shell material: Wave patterned aluminum reinforced structure.
Installation method: Standard industrial 35mm rail installation.
Data and Storage:
Storage: Configure 128KB flash memory (for programs and firmware) and 256KB dual port RAM (for data and programs).
Message processing: Supports a maximum of 255 byte input/output buffer, with a nested message depth of 2 levels.
Bus current: The required bus current is 300mA.
Environmental adaptability:
Working temperature range: 0 ° C to 60 ° C.
Storage temperature range: -40 ° C to 85 ° C.
Relative humidity: 95% (without condensation).
Working altitude: ≤ 5000m.
Anti interference capability: Complies with IEC 801-3 standard, with an anti electromagnetic interference capability of 10V/m (80-1000MHz).
Compatibility: Compatible with all CPUs in the Quantum series, supporting programming software such as Concept 2.5 and above, ProWorx NxT, ProWorx 32, etc.
Communication protocol: Supports ASCII transmission protocol, data formats include text, decimal, fixed-point, etc., supports advanced functions such as nested message writing and setting register pointers.
