140NOE77100C Schneider Relay Module
140NOE77100C is an Ethernet network TCP/IP module from Schneider Electric's Modicon Quantum series, designed specifically for efficient Ethernet communication between Modicon Quantum PLC and other devices. This module adopts the standard Modicon Quantum single width chassis structure, which can flexibly occupy any slot in the backplane and support hot swapping function, making it easy to maintain and upgrade. Its physical interface covers 10BASE-T/100BASE-TX (copper cable) and 100BASE-FX (fiber optic cable), with a transmission rate of 10/100Mbps, ensuring fast and stable data transmission. The module is equipped with 10 LED indicator lights, which can intuitively display key information such as data rate, conflict detection, download mode, fault status, network status, full duplex mode, module readiness, network activity, rack operation, and transmission activity, making it easy for users to monitor the real-time operation status of the module. In addition, the 140NOE77100C is compatible with all Modicon Quantum CPUs and supports software such as Unity Pro 2.0, Concept, and ProWORX 32, providing users with flexible programming and configuration options. Its sturdy wavy aluminum reinforced casing design, combined with IP30 protection level, ensures that the module can still operate stably in harsh industrial environments.
Technical specifcations for 140NOE77100C
The product series and types belong to the Modicon Quantum automation platform, which is an Ethernet TCP/IP module
The communication port protocol supports Ethernet Modbus TCP/IP protocol
The physical interface includes MT/RJ-100BASE-FX fiber optic interface and RJ45-10BASE-T/100BASE-TX twisted pair interface, with a transmission rate of 10/100 Mbit/s
The local signal indicator is equipped with 10 LED lights, which are used to indicate 10 Mbps or 100 Mbps data rate, conflict detection, download mode, Ethernet module failure, Ethernet network status, full duplex mode, module readiness, network activity, rack operation, and send/receive activity
The current consumption is 750 mA under a 5V DC power supply
The module classification and net weight module classification are not explicitly mentioned, with a net weight of 0.345 kg
The environmental adaptability IP level is IP20, which complies with the cUL UL 508 standard
The product certification complies with FM Class 1 Part 2, CSA C22.2 No 142 standard, with 4 kV contact protection, anti-static discharge in accordance with IEC 801-2 standard (8 kV broadcast), and anti electromagnetic interference in accordance with IEC 801-3 standard (10 V/m, 80-1000 MHz)
Operating and storage environment operating temperature range is 0-60 ° C, storage environment temperature range is -40-85 ° C, relative humidity is 95% (no condensation), working altitude does not exceed 4500 m
The contract warranty period is 18 months
Compatibility and software support: Compatible with all Modicon Quantum CPUs, supporting Unity Pro 2.0, Concept, ProWORX 32, and other software
