140CRA93200C Schneider Relay Module
140CRA93200C is an RIO Drop Adapter module from Schneider Electric's Modicon Quantum series, mainly used to expand the I/O function of Modicon Quantum PLC systems. It supports redundant connections and can extend RIO subnets to up to 27 nodes, making it suitable for high reliability industrial automation control systems; This module adopts a dual cable design, supports S908 RIO bus protocol, has a transmission rate of 1544 Mbit/s, and is equipped with 4 LED indicator lights for displaying ready, communication, error A and error B status, making it easy for users to monitor the operation of the module; Its working temperature range is 0 ° C to 60 ° C, storage temperature range is -40 ° C to 85 ° C, protection level is IP20, and it adopts standard industrial 35mm rail installation method to ensure stable operation in harsh industrial environments.
Technical specifcations for 140CRA93200C
Product Series Modicon Quantum Automation Platform
Product Type RIO Branch Adapter Module
Compatibility can be used with Quantum 200 series, 500 series, 800 series, or SY/MAX (any combination), supporting up to 27 I/O expansion modules
Cable type 75 Ω coaxial cable, supporting redundant cable connections
Transmission rate 1544 Mbit/s
Dynamic range 35 dB
Isolation voltage 500 V DC (coaxial center and ground)
Electrical connection 2-hole terminal F, curved design
The indicator light is equipped with 4 LED indicators, which are used to indicate the ready status, communication status, error A, and error B respectively
Typical power consumption is 3.8 W
Require bus current of 750 mA (2 channels)
Module classification standard environment
Compliant with CSA C22.2 No 142, CUL UL 508, anti-static discharge 4 kV contacts (compliant with IEC 801-2), 8 kV broadcast (compliant with IEC 801-2), anti electromagnetic interference 10 V/m 80-1000 MHz (compliant with IEC 801-3)
Working temperature 0-60 ° C
Storage environment temperature -40-85 ° C
Relative humidity 95% (no condensation)
Working altitude ≤ 5000 meters
