Name: 140DAI44000C PLC (Programmable Logic Controller) module
Brand: Xiamen Online Union Technology Co., Ltd
SKU: 140DAI44000C
Price: 99 USD
Availability: InStock

Home Products Schneider Module

140DAI44000C PLC (Programmable Logic Controller) module

Product Details:

Place of Origin:	China
Brand Name:	Schneider
Model Number:	140DAI44000C

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	$99
Packaging Details:	New sealed
Delivery Time:	In stock/1-3days
Payment Terms:	T/T
Supply Ability:	5000

Contact Now

Detailed Product Description

Highlight:

industrial automation schneider module

automation control schneider module

plc controller schneider module

140DAI44000C Schneider Relay Module

140DAI44000C is a product of Schneider brand, belonging to the PLC (Programmable Logic Controller) module. Its structural form is modular, and the installation method is usually installed in the control room. It adopts the LD instruction processor of hard PLC and has I/O module function. The working voltage is 48V and the output frequency is 50Hz. It can be used in the field of industrial automation to achieve specific input/output control functions

Technical specifcations for 140DAI44000C

Input specifications:
Input quantity: 16 inputs
Input voltage: Supports 48V AC voltage input, voltage state 1 guarantee range is 36-56V AC (47-53Hz), 34-56V AC (57-63Hz); The voltage state 0 guarantee range is 0-10V (47-53Hz), 0-10V (57-63Hz)
Input impedance: 6800 Ω (capacitive, 47-53Hz), 5600 Ω (capacitive, 57-63Hz)
Leakage current: ≤ 1.7mA
Absolute maximum input: 63V (10 seconds), 56V (continuous), 100V (1 cycle)
Response characteristics:
Reaction time: Open close 7.3-12.3ms, close open 4.9-0.75ms x line cycle
Electrical isolation:
Inter group insulation: 1780Vrms for 1 minute
Power supply and power consumption:
Required bus current: 180mA
Power consumption: ≤ 5.5W
Signal indication:
Local signal: 16 green LED indicator lights display input status (1 to 32), 1 red LED indicator light detects external faults (F), 1 green LED indicator light displays bus communication activity status
Physical characteristics:
Product weight: 0.3kg
Installation and configuration:
Structural form: modular design
Installation method: Control room installation
Address requirement: 1 input word
Output current: ≤ 9.3mA (47-53Hz), ≤ 11mA (57-63Hz)
