110CPU51203 Schneider Relay Module
110CP51203 is a high-performance programmable logic controller (PLC) processor unit under Schneider Electric, belonging to the Unity Pro series. This product is designed specifically for industrial automation scenarios, integrating powerful computing cores and rich communication interfaces to efficiently execute complex control logic and data processing tasks. It supports multiple programming languages (such as ladder diagrams, structured text, etc.) and has real-time multitasking capabilities to ensure system response speed and stability. Modular design allows for flexible expansion of I/O modules and functional units, adapting to industrial applications of different scales and requirements. In addition, 110CP51203 has high anti-interference ability and wide temperature working characteristics, which can operate stably in harsh environments. It is widely used in manufacturing, process control, infrastructure and other fields, and is the core component of industrial automation systems.
Technical specifcations for 110CPU51203
Hardware specifications
Processor performance:
Adopting high-performance processors, supporting real-time multitasking operations, suitable for complex control logic and high-speed data processing.
Memory configuration:
User program memory: typically several megabytes (specific capacity to refer to official data manual), supporting program and data storage.
Power outage maintenance: Built in battery or capacitor backup ensures that RAM data is maintained in the event of a power outage.
Communication interface:
Ethernet port: Integrated 10/100 Mbps Ethernet interface, supporting Modbus TCP/IP protocol.
Serial communication: Supports RS-485/RS-32 interfaces and is compatible with Modbus RTU protocol.
Scalability: Industrial buses such as Profibus and CANopen can be expanded through modules.
I/O expansion capability:
Support local expansion rack, up to multiple I/O modules can be connected (specific quantity needs to refer to the manual).
Support remote I/O distributed architecture and adapt to complex system requirements.
Power supply and power consumption:
Power type: DC 24V input (specific range subject to manual).
Power consumption: varies dynamically according to configuration, with a typical value of about 10-20W.
Software and Programming
Programming environment:
Compatible with Unity Pro or SoMachine software, supporting programming languages such as ladder diagram (LD), functional block diagram (FBD), structured text (ST), etc.
Task management:
Support multitasking operating systems, configurable for periodic tasks and event triggered tasks.
The task cycle time can reach milliseconds, meeting the requirements of high-speed control.
Diagnosis and debugging:
Built in self diagnostic function, real-time monitoring of hardware status and program operation.
Support online debugging, variable monitoring, and remote maintenance.
Environment and reliability
Working conditions:
Temperature range: 0 ° C to+60 ° C (operation), -20 ° C to+70 ° C (storage).
Humidity: 5% to 95% (non condensing).
Protection level:
The rack and modules usually comply with the IP20 standard and are suitable for installation inside control cabinets.
Anti interference capability:
Compliant with IEC 61131-2 standard, with electromagnetic compatibility (EMC) and surge protection.
Certification and Standards
Compliant with international standards (such as IEC 61131-3) and EU CE certification.
Meet safety and environmental protection requirements in industrial environments.
