TSXP57204M Schneider Relay Module
TSXP57204M is a high-end programmable controller from Schneider Electric's Modicon Premium series, with powerful processing capabilities and stability. It is equipped with a high-performance processor that can efficiently execute complex control tasks. Its Boolean instruction execution time is only 37ns, and the numerical instruction execution time is only 45ns, ensuring high-speed and stable computation; Support multiple communication interfaces, such as Ethernet, serial port, CAN bus, etc., for easy data exchange with other devices and systems; Provide flexible I/O configuration, which can connect various sensors, actuators, and external devices to meet the needs of industrial process monitoring and control; Equipped with large capacity memory for storing control programs, data, and configuration files; Built in real-time operating system, capable of responding to input signals and executing control logic in real-time, ensuring system stability and reliability; Supports multiple programming languages, such as LD (ladder diagram) and FBD (functional block diagram) under the IEC 61131-3 standard, making it easy for users to write, debug, and execute control programs; Has high scalability and flexibility, supports modular design, can be expanded and upgraded according to actual needs, flexible hardware configuration and software functions, easy to customize and optimize; Equipped with comprehensive security protection functions, including input/output protection, power protection, communication protection, etc., to ensure stable and reliable operation in harsh environments, it is widely used in industrial fields such as manufacturing, energy, transportation, etc. that require high-performance control.
Technical specifcations for TSXP57204M
Processor performance:
The execution time of Boolean instructions is only 37ns, and the execution time of numerical instructions is only 45ns, ensuring high-speed computing capability.
Storage capacity:
The integrated storage capacity is 192Kb, which can be expanded to a maximum of 768Kb through PCMCIA cards to meet large-scale program storage requirements.
Bus and network support:
Supports 3 fieldbuses, 8 AS-I buses, and 1 CANopen bus, compatible with multiple industrial communication standards.
Supports multiple communication interfaces such as Ethernet, serial port, CAN bus, etc., facilitating data exchange with other devices and systems.
I/O points:
Supports 2048 I/O points and can connect various sensors, actuators, and external devices to achieve monitoring and control of industrial processes.
Protection level and design:
Adopting industrial grade design, with a protection level of IP30, equipped with a corrugated aluminum reinforced casing, supporting 35mm DIN rail installation, suitable for harsh industrial environments.
Power supply and protection:
Supports DC (9-36) V wide power input, with dual power redundancy and isolation protection functions, and can switch to backup power in case of power failure.
The electrical interface has 4000V lightning protection, 1.5A overcurrent protection, and 600W surge protection functions to ensure stable operation of the equipment in harsh environments.
Communication speed and interface:
The data electrical interface adopts a 9-pin Sub-D socket connector, and the pin definitions comply with the protocol specifications of Profibus DP.
Supports multiple commonly used rates for Profibus DP bus, including 9.6kBit/s to 12MBit/s, which can be manually set or rate adaptive through dip switches.
The fiber optic interface supports multi-mode wavelengths of 850nm and 1310nm, as well as single-mode wavelengths of 1310nm and 1550nm. The transmission distance can reach 2Km for multi-mode and 20km for single-mode, with options for longer distances.
Environmental adaptability:
The working temperature range is -20 ℃ to+60 ℃, and the electromagnetic compatibility has been certified by EMC testing, making it suitable for complex electromagnetic environments in industrial sites.
Status indication and alarm:
Equipped with 6 dual color LED status indicator lights, real-time display of device operation status.
Equipped with power failure relay output alarm function, with a large contact capacity of DC48V/1A for easy troubleshooting.
