TSXPSY3610MC Schneider Relay Module
The TSXPSY3610MC model product is a power module launched by Schneider Electric, belonging to its Modicon Premium automation platform series products. This product adopts a modular structure, supports 35mm DIN rail installation, has an IP30 protection level, and is suitable for industrial control room environments. Its core function is to provide stable power supply for racks and modules, support 24VDC non isolated power supply (power 50W), and be compatible with 100-240VAC wide voltage input. The module is equipped with a battery slot, which can ensure that the internal RAM data of the PLC is saved for up to one year after power failure. At the same time, it integrates alarm relays, RESET buttons, and status indicator lights (OK, BAT, 24V) for real-time monitoring of power status. The product has passed multiple electromagnetic compatibility tests (such as IEC61000-4 series standards) to ensure stable operation in complex electromagnetic environments, and is suitable for scenarios in industrial automation systems that require high power reliability and safety.
Technical specifcations for TSXPSY3610MC
Brand and Model: The brand is Schneider and the model is TSXPSY3610MC.
Power Supply and Power: This product provides a 24VDC non isolated power supply with a power of 50W, and supports a wide voltage input of 100-240VAC, which can adapt to different power supply environments.
Installation method: Adopting 35mm DIN rail installation, convenient for installation and wiring in industrial control cabinets.
Protection level: The shell protection level is IP30, with a certain degree of dust-proof ability, suitable for industrial control rooms and other environments.
Working temperature and humidity: The working temperature range is -10 ℃ to 70 ℃ (with a wide temperature range of -40 ℃ to+85 ℃), and the relative humidity does not exceed 90% (without condensation). It can work stably in harsh industrial environments.
Electromagnetic compatibility: The product has passed multiple electromagnetic compatibility tests, including the IEC61000-4 series standards, such as anti-static discharge (ESD) air ± 8KV, contact ± 4KV, anti radiation electromagnetic field (RS) 10V/m (80-1000MHz), etc., to ensure stable operation in complex electromagnetic environments.
Display and indication: Equipped with OK indicator light (green, lit when voltage is present and correct), BAT indicator light (red, lit when battery failure or absence), and 24V indicator light (green, lit when sensor voltage is present, depending on the model), convenient for users to monitor module status in real time.
Other features:
Contains a RESET pencil tip button for hot start of applications.
Equipped with a battery slot to protect the internal RAM of the processor.
Provide screw terminal blocks for connecting main power supply, alarm relay contacts, sensor AC power supply (depending on the model), etc.
There is a fuse located below the module to protect the 24VR voltage (for non isolated DC power sources).
Some models may be equipped with a 110/220 voltage selector.
