TSX3721101 Schneider Relay Module
TSX3721101 is an analog input/output module of the TSX series PLC (Programmable Logic Controller) launched by Schneider Electric, belonging to the Micro series module controller. This module adopts modular design and supports flexible expansion. Users can choose suitable modules according to their actual needs and adjust them according to business expansion. It provides analog input and output functions, capable of processing continuously changing signals such as temperature, pressure, and flow rate, suitable for industrial automation scenarios that require precise measurement and control. The module supports 24VDC power supply (19.2~30V), with 8 analog inputs (0~10V) and 1 analog output (0~10V), and integrates a 10kHz fast counter to meet complex control requirements. In addition, the module adopts a compact design, occupies a small space, is easy to install and maintain, and has passed strict quality control and international standard certification to ensure stable operation in harsh environments such as high temperature, low temperature, and humidity. It also supports Windows based on IEC 1131-3 ™ The programming software supports Ladder Logic (LD), Instruction List (IL), or Sequential Flow Chart (SFC) language programming, and provides PCMCIA memory expansion and communication ports to further expand system functionality.
Technical specifcations for TSX3721101
Brand and Model: The brand is Schneider and the model is TSX3721101.
Power supply: Supports 24VDC power supply, with a working voltage range of 19.2-30V DC and a power consumption of less than 4W. It has DC1500V voltage isolation and reverse protection functions.
Analog input and output:
Analog input: 8 analog input channels, with an input range of 0~10V.
Analog output: 1 analog output channel with an output range of 0~10V.
Counter: Integrated with one 10kHz fast up/down counter.
Mechanical characteristics:
Dimensions: 132mm × 105mm × 52mm.
Shell protection level: IP30.
Installation method: 35mm DIN rail installation.
Net weight: 800g.
Work environment:
Working temperature: -10~70 ℃ (wide temperature options -40~+85 ℃).
Relative humidity: ≤ 90% (no condensation).
Storage temperature: -40~80 ℃.
Test certification: The product has passed multiple electromagnetic compatibility tests, including but not limited to:
IEC61000-4-2 (ESD): Air discharge voltage ± 8KV, contact discharge voltage ± 4KV, Criteria: B Level 2.
IEC61000-4-3(RS):3V/m(80~1000MHz),Criterion:A Level 2.
Expansion and Communication:
Memory expansion: Supports PCMCIA memory expansion, with a maximum of 64K words.
Communication port: Equipped with PCMCIA communication port, it can be used to add expansion shelves to further expand system functionality.
Other features:
Programming software: based on IEC 1131-3 Windows ™ The programming software supports Ladder Logic (LD), Instruction List (IL), or Sequential Flow Chart (SFC) programming languages.
Integration: It has good integration and can seamlessly connect with other systems and devices. Schneider provides simple and intuitive management tools and interfaces, allowing users to easily configure, monitor, and manage modules.
