Name: TSXDMZ28AR discrete I/O module
Brand: Xiamen Online Union Technology Co., Ltd
SKU: TSXDMZ28AR
Price: 99 USD
Availability: InStock

Home Products Schneider Module

TSXDMZ28AR discrete I/O module

Product Details:

Place of Origin:	China
Brand Name:	Schneider
Model Number:	TSXDMZ28AR

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	$99
Packaging Details:	New sealed
Delivery Time:	In stock/1-3days
Payment Terms:	T/T
Supply Ability:	5000

Contact Now

Detailed Product Description

Highlight:

industrial automation schneider module

automation control schneider module

plc controller schneider module

TSXDMZ28AR Schneider Relay Module

TSXDMZ28AR is a discrete I/O module from Schneider Electric's Premium series, equipped with 16 point 100-120V AC input (unprotected) and 12 point 50VA relay output (unprotected) functions. It adopts a screw terminal block connection method and supports quick installation. It is suitable for mid to low frequency load control scenarios in industrial automation control systems (such as relay drive); Its full height module design is matched with a corrugated aluminum reinforced casing, with a protection level of IP30 and a working temperature range of -10 ° C to+70 ° C (conventional version). The input terminal supports 100-120V AC voltage, and the output contact capacity is 50VA. Through configuration software, specific inputs can be assigned functions such as discrete input, latch input, event triggered input, or up/down counter input. For example, the first four inputs can be configured as latch input or event triggered input, and support the RUN/STOP command to control the PLC through input% I1.8. It is suitable for industrial production line logic control and equipment status monitoring applications.

Technical specifcations for TSXDMZ28AR

Brand and Model:
Brand: Schneider Electric
Model: TSXDMZ28AR
Product type and function:
Product type: Discrete I/O module
Main function: Suitable for discrete input/output control in industrial automation control systems
Input parameters:
Input points: 16 points
Input type: 100~120V AC input (unprotected)
Output parameters:
Output points: 12 points
Output type: 50VA relay output (unprotected)
Load capacity: Supports relay switches, suitable for loads such as solenoid valves and contactors
Connection method:
Using screw terminal block connection, supporting quick installation
Appearance and Design:
Module design: Full height module
Shell material: Wave patterned aluminum reinforced shell
Protection level: IP30
Weight: Approximately 800g (refer to similar modules)
Electrical parameters:
Input voltage: 100~120V AC (input terminal)
Output contact capacity: 50VA (relay output)
Environmental adaptability:
Working temperature range: Normal range -10 ° C to+70 ° C (specific wide temperature version needs to be confirmed)
Configuration and Function Expansion:
By configuring the software, specific functions can be arranged for specific inputs, such as discrete input, latch input, event triggered input, or up/down counter input.
