Mitsubishi Q61P 190235 PLC Q Series Power supply 100-240 V AC input, 5 V DC 6 A output
Product Description:
The Mitsubishi Q61P is a compact and highly reliable power supply module designed specifically for the MELSEC-Q series of programmable logic controllers. This module serves as the foundational component of any Q-series PLC system, responsible for converting the incoming alternating current (AC) line power from a panel source into a stable, regulated direct current (DC) supply. This DC power is essential for operating the PLC's CPU module, I/O modules, and any other special function modules installed on the same base unit.
Engineered for industrial environments, the Q61P ensures the integrity and stable operation of the entire PLC rack by providing clean and consistent power, which is critical for preventing malfunctions and data errors. Its design prioritizes simplicity and durability, featuring a built-in cooling fan to maintain optimal operating temperatures and ensure long-term performance. The module is easily installed on the main base unit and is a mandatory first step in building a robust and dependable MELSEC-Q control system for a wide range of automation applications, from factory assembly lines to complex process control.
Technical Specifications:
The Mitsubishi Q61P is a power supply module with an input voltage rating of 100 to 240 V AC, allowing it to be used with a wide range of standard single-phase industrial power sources worldwide. The input frequency range is 50/60 Hz. Its primary function is to output a stable 5 V DC voltage to the base unit's backplane, with a maximum output current of 6 A, providing 30 W of power for the system modules.
The module incorporates protective features including overcurrent and overvoltage protection to safeguard both the power supply itself and the connected modules from electrical faults. For thermal management, it includes an internal cooling fan to ensure reliable operation within its specified ambient temperature range of 0 to 55 degrees Celsius. The module is designed for mounting on a main base unit and has a physical weight of approximately 0.4 kg. Its construction is rated for use in environments with a relative humidity of 5% to 95% (non-condensing) and an altitude of up to 2000 meters. It complies with key international standards for safety and EMC, ensuring its suitability for global industrial applications.
