Name: ZKB Series Mitsubishi Magnetic Powder Clutch And Brake Tension Control
Brand: Xiamen Online Union Technology Co., Ltd
SKU: ZKB-0
Price: 50.00 USD
Availability: InStock

Home > Products > Mitsubishi Module >

ZKB Series Mitsubishi Magnetic Powder Clutch And Brake Tension Control

Mitsubishi magnetic powder clutch

Mitsubishi tension control brake

ZKB series powder clutch

Place of Origin:

Japan

Brand Name:

MITSUBISHI

Model Number:

ZKB-0

Request A Quote

ZKB Series Mitsubishi Magnetic Powder Clutch And Brake Tension Control

Product Details

YN:

Extended Shaft, Natural Cooling

AN:

Standard Solid Shaft, Natural Cooling

BN:

Standard Solid Shaft, Forced Air Cooling (built-in Fan)

XN:

Standard Solid Shaft, Natural Cooling (General Purpose)

WN:

Water-cooled (for Extreme Heat Dissipation)

HBN:

High-performance Forced Air With Enhanced Heat Sink

Highlight:

Mitsubishi magnetic powder clutch

Mitsubishi tension control brake

ZKB series powder clutch

Payment & Shipping Terms

Minimum Order Quantity

Price

1-99$

Packaging Details

Brand New Original

Delivery Time

in stock / 1-3 work days

Payment Terms

T/T

Supply Ability

999

ZKB Series Mitsubishi Magnetic Powder Clutch And Brake Tension Control

Get Best Price

FR-A740-00023-EC Mitsubishi Electric FR-A700 Series High Performance Vector Inverter

Get Best Price

HG-KR43B MITSUBISHI Servomotor HG Series, Power 400 W

Get Best Price

QX10 129581 MITSUBISHI PLC Q Series Input Module

Get Best Price

Contact Now

Product Description

ZKB Series Mitsubishi Magnetic Powder Clutch And Brake Tension Control

Product Overview

The Mitsubishi ZKB Series represents a premium line of Magnetic Powder Clutches and Brakes designed for high-precision industrial tension control. While "ZKB-0" typically refers to the base series designation in ordering systems, the specific models are defined by suffixes and torque ratings (e.g., ZKB-0.06AN, ZKB-0.3YN, ZKB-1.2BN).

These units are the "muscle" behind web handling machinery, utilizing magnetic powder to transmit torque smoothly and linearly. When voltage is applied to the stationary coil, magnetic particles align to create a solid magnetic chain, connecting the input and output shafts without physical contact. This provides exceptional durability, instant response, and precise torque regulation for applications ranging from paper printing to steel processing.

Key Features & Benefits

Linear Torque Control: Torque is strictly proportional to the excitation current, allowing for precise adjustments from 0% to 100% of rated torque simply by varying the voltage (0-24V DC).
Non-Contact Operation: Since there is no mechanical friction between the rotating parts (only magnetic coupling), wear is virtually eliminated, ensuring a long service life and maintenance-free operation.
High Heat Dissipation: Designed with robust aluminum housings and cooling fins. Larger models (BN/WN/HBN series) feature built-in air ducts or internal cooling fans to handle high-slip heat generation.
Instant Response: Extremely fast actuation time (milliseconds) makes these ideal for dynamic tension correction systems.
Smooth Operation: Magnetic powder ensures "soft" start and stop characteristics, preventing web breakage or material damage (e.g., film stretching, paper tearing).
Versatile Mounting: Available in various shaft configurations (Solid shaft, Hollow shaft, Double shaft) to fit different mechanical designs.

Technical Specifications (Selected Models)

The "ZKB-0" prefix covers a wide range of torque capacities. Below are the most common industrial standards:

Model Suffix	Rated Torque (N·m)	Rated Current (A)	Max Allowable Speed (rpm)	Moment of Inertia (kg·m²)	Weight (kg)	Cooling Method	Application
ZKB-0.06AN	0.6	0.46	1800	6.1×10⁻⁵	1.7	Natural Air	Light tension, small rollers
ZKB-0.3AN	3.0	0.53	1800	3.0×10⁻⁴	3.1	Natural Air	Printing presses, labeling machines
ZKB-0.6AN	6.0	0.81	1800	6.0×10⁻⁴	3.7	Natural Air	Packaging machinery, wire coating
ZKB-1.2BN	12.0	1.20	1500	1.1×10⁻³	6.5	Forced Air (Fan)	Paper making, medium-duty winders
ZKB-2.5BN	25.0	1.80	1200	2.5×10⁻³	11.0	Forced Air (Fan)	Steel strip processing, laminators
ZKB-5.0BN	50.0	2.50	1000	4.8×10⁻³	18.0	Forced Air (Fan)	Heavy-duty unwinders/rewinders
ZKB-10BN	100.0	3.80	800	9.5×10⁻³	32.0	Forced Air (Fan)	High-tension industrial lines

Suffix Key

AN: Natural cooling, general purpose.
YN: Extended shaft, natural cooling.
BN: Forced air cooling (built-in fan/duct), high torque.
WN: Water-cooled (for extreme heat dissipation).
HBN: High-performance forced air with enhanced heat sink.

Typical Applications

The ZKB series is essential for any industry processing "web" materials:

Printing & Paper: Web tension control on offset printers, flexo printers, and paper cutters.
Packaging: Film unwinding/rewinding, bag making machines, and labeling units.
Textiles: Yarn twisting, weaving looms, and fabric calendering.
Metallurgy: Tension control for aluminum foil, copper foil, and steel strip annealing lines.
Plastics: Extrusion lines, blow molding, and sheet calendering.
Cable & Wire: Insulation coating and stranding machines.

System Integration

To function, the ZKB unit must be paired with a Tension Controller (such as Mitsubishi's LE-40MTA or LD-30FTA) and a Tension Sensor (Load cell or dancer roller).

The sensor detects the actual tension of the material.
The controller compares the actual tension to the setpoint.
The controller adjusts the DC voltage (0-24V/90V) sent to the ZKB clutch/brake.
The ZKB adjusts the torque output to maintain perfect tension.

Ordering Information

Manufacturer: Mitsubishi Electric
Product Family: ZKB Series (Magnetic Powder Clutch/Brake)
Note on "ZKB-0": When ordering, the "0" is a placeholder for the specific torque rating. You must specify the full model number (e.g., ZKB-0.6AN) based on the required torque and cooling method.
Compatibility: These units are compatible with universal tension controllers (0-10V or 0-24V DC output) from brands like Mitsubishi, Keyence, and Panasonic.
