Name: HG-KR73 MITSUBISHI Servomotor HG Series, Power 750 W
Brand: Xiamen Online Union Technology Co., Ltd
SKU: HG-KR73
Price: 50.00 USD
Availability: InStock

Home > Products > Mitsubishi Module >

HG-KR73 MITSUBISHI Servomotor HG Series, Power 750 W

Mitsubishi HG-KR73 servomotor

750W HG series servomotor

Mitsubishi servomotor with warranty

Place of Origin:

Japan

Brand Name:

MITSUBISHI

Model Number:

HG-KR73

Request A Quote

Product Details

Series:

MELSERVO-J4

Type:

HG-KR

Power Supply (V):

200

Rated Capacity (kW):

0,75

Inertia:

LOW INERTIA

Rated Torque (Nm):

2,4

Maximum Torque (Nm):

8,4

Rated Speed (rpm):

3.000

Inertia (kg*cm2):

1,26

Brake:

Shaft Type:

STRAIGHT SHAFT

Current Type:

Encoder Resolution (p/rev):

4.194.304

Maximum Speed (rpm):

6.000

Protection Class:

IP65

Encoder Type:

22-BIT

Highlight:

Mitsubishi HG-KR73 servomotor

750W HG series servomotor

Mitsubishi servomotor with warranty

Payment & Shipping Terms

Minimum Order Quantity

Price

1-99$

Packaging Details

Brand New Original

Delivery Time

in stock / 1-3 work days

Payment Terms

T/T

Supply Ability

999

Q06UDVCPU Mitsubishi High Speed Module General Purpose CPU Module

Get Best Price

ZKB-0.6YN MITSUBISHI High Precision Magnetic Particle Brake DC 24V 1800 R/Min

Get Best Price

RM100C2Z-H Mitsubishi High Precision Module Low Profile Electronic Module

Get Best Price

QY81P Mitsubishi 32 Points Module Output Module Overview 24VDC

Get Best Price

Contact Now

Product Description

HG-KR73 MITSUBISHI Servomotor HG Series, Power 750 W

MITSUBISHI HG-KR73 Servomotor HG Series, Power 750 W

Servomotor HG Series, Power 750 W; Torque 2.4 Nm, Max. Torque 8.4Nm

The HG-KR73 belongs to Mitsubishi's MR-J4 series servo motors, optimized for dynamic performance in machinery requiring rapid acceleration/deceleration and precise positioning. Its compact design (total length of 130mm) and lightweight construction (2.8kg standard, 3.8kg with brake) make it suitable for space-constrained applications. The motor features a 22-bit absolute/incremental encoder (4,194,304 pulses/rev) for sub-micron positioning accuracy and includes built-in vibration suppression to enhance low-speed stability.

Key Technical Specifications

Power & Torque:

Rated output	750W
Rated torque	2.4 Nm (continuous) / 8.4 Nm (peak, 350% of rated)
Rated speed	3,000 RPM (max speed: 6,000 RPM,瞬时允许转速: 6,900 RPM)

Electrical:

Rated current	4.8A (max: 17A)
Recommended servo amplifier	MR-J4-70A (750W class)
Power supply	200-240V AC (compatible with MR-J4 series drives)

Mechanical:

Inertia	1.26 × 10⁻⁴ kgm² (standard), 1.37 × 10⁻⁴ kgm² (with brake)
Recommended load inertia ratio	≤17:1
Shaft load capacity	Radial 392N/Axial 147N (at 40mm from flange)

Environmental:

Protection	IP65 (dust/water-resistant, suitable for harsh environments)
Operating temperature	0°C to 40°C (storage: -15°C to 70°C)
Humidity tolerance	80% RH (non-condensing)

Features:

Low-inertia design for fast response (0->3,000 RPM in 30ms)
Auto-tuning function for PID optimization via MR Configurator2 software
Optional electromagnetic brake (2.4 N*m static torque, DC24V)
Oil seal and IP67-rated connector (select variants)
