140MSB10100 Schneider Relay Module
140MSB10100 is a single axis motion control module launched by Schneider Electric, which belongs to programmable control system components. It adopts modular design, supports Profibus DP bus standard, has 9-pin Sub-D socket connector, communication speed covers the range of 9.6kBit/s to 12MBit/s, compatible with dual power redundant input (DC9-36V, typical DC24V), power consumption is less than 4W, built-in power isolation and reverse connection protection function, equipped with 6 dual color LED status indicator lights and power fault relay output alarms. It has passed industrial EMC testing certification, has 4000V lightning protection, 1.5A overcurrent protection and 600W surge protection function, and the protection level reaches IP30. It adopts wavy aluminum reinforced chassis and standard industrial 35mm rail installation method. Suitable for scenarios in the field of industrial automation that require high precision in motion control and system stability.
Technical specifcations for 140MSB10100
Brand and Model:
Brand: Schneider Electric
Model: 140MSB10100
Product type and function:
Product type: Single axis motion module
Main functions: Supports synchronization of master/slave speed and position, and can perform automatic control of linear, rotational, or continuous axes, including return motion, relative motion, continuous movement, and other motion modes. Supports loop position control functions such as position capture (stop).
Performance indicators:
Axis update time: 1ms position loop, 0.5ms speed loop
System accuracy: 0.5 arc/minute encoder related
Sports program: Supports 28 traversal programs and 650 flash commands
Interface and Connection:
Encoder voltage: 5V+/-20%
Encoder impedance: 500 ohms
Incremental encoder frequency: 500 kHz in x1 mode, 2000 kHz in x4 mode
Analog output: Bipolar output+/-10... 24 V, 11 bit+symbol servo interface
Discrete output: Drive enable output<=30 V, 3 auxiliary outputs 24 V (150 mA), servo interface drive enable output 24 V (500 mA)
Discrete input: Auxiliary input 24V, driver fault input servo interface 5V TTL (dry contact OT input)
Analog input range:+/-10... 24 V, 30000 Ohm auxiliary input
Analog output range:+/-10... 24 V, 11 bits+symbol, 0.003 A auxiliary output
Electrical connection: 1 connector SUB-D 9 RS232 Modbus link, 1 connector SUB-D 50 connected to servo drive
Communication and Protocol:
Communication port protocol: Modbus serial line from RS232, supporting communication rates of 300.. 9600 bit/s
Supports Profibus DP bus standard, with a communication speed range of 9.6kBit/s to 12MBit/s
Power supply and protection:
Power supply: dual power redundant input, DC(9-36)V, Typical DC24V, power consumption less than 4W
Power protection: with DC1500V voltage isolation and reverse connection protection function
Relay alarm output: link fault and power fault alarm output, large contact capacity: DC48V/1A
Environmental adaptability:
Operating environment air temperature: 0... 60 ° C (32... 140 ° F)
Storage environment air temperature: -40... 85 ° C (-40... 185 ° F)
Relative humidity: 95% without condensation
Protection level: IP30
Anti static discharge: 4 kV contact IEC 801-2, 8 kV overhead IEC 801-2
Electromagnetic field resistance: 9.14 V/m (10 V/m) 80... 1000 MHz IEC 801-3
Physical characteristics:
Module format: Standard
Net weight: 0.45 kilograms (0.99 pounds)
Shell material: Wave patterned aluminum reinforced shell
Installation method: Using standard industrial 35mm guide rail installation method
